LEDPanelS-P7 Sq620-22/29W-865-U19

Electrical data

Nominal voltage	220|240 V
Voltage type	AC/DC
Max. system power	33 W
Max. number of luminaires per miniature circuit breaker B16 (MCB)	18
Max. number of luminaires per miniature circuit breaker C16 (MCB)	44
Power factor	0.9
Surge protection	2 kV
With sensor	No
Max. inrush current	40 A
Inrush time	250
Displacement factor (DF)	≥ 0.9
Max. number of luminaires per miniature circuit breaker C10 (MCB)	27
Max. number of luminaires per miniature circuit breaker C13 (MCB)	35
Including emergency lighting	No
Nominal voltage DC	180|280 V
Frequency	50|60 Hz

Photometrical data

Colour temperature	6500 K
Equivalent to	TL 4x18W
Colour consistency (SDCM)	3
Colour rendering index (CRI)	> 80

Light technical data

Beam angle	90°
UGR	19

Lifespan

Lifetime (L70)	100000 h
Lifetime (L80)	70000 h
On-/Off-cycles	100000
Lifetime (L90)	50000 h

Capabilities

Dimmability	On-Off
With sensor	No
Sensor technology	No sensor

Certificates and standards

Protection class according to IEC 61140	II
Impact strength	IK03
Glow wire test	650°C
IP recessed part	IP40
Risk group (EN 62471)	RG0

Type of control gear	LED operating device current-controlled
With control gear	Yes
Driver failure rate (at 5,000 hrs)	1%
Input current	0.135 A
Max. input cable diameter	0.75|1.5 mm
Wirethrough	No

Housing colour	White
Cover material	Polystyrene
Lens material	PMMA
Finishing	White RAL9003
Pressure valve	No
Coastal proof	No

Length	620 mm
Width	620 mm
Height/depth	34 mm

Application temperature	25°C
Storage environment	-20|50°C
Operating temperature	-10|45°C
